廣州車嘉電子科技有限公司專業生產及銷售車載通用、專用DVD/GPS導航系統，汽車頭枕、臺式
后視鏡等液晶顯示器，車載全景系統、倒車攝像頭、倒車雷達、DVB-T\ISDB\ATSC-M\等一系列汽車
影音產品，產品遠銷歐美，日本，東南亞地區。
  Guangzhou CACAR Electronics Technology Co.,Ltd Specializing in car DVD，ISDB-T TV,
ATSC-M, DVB-T MPEG4, DVB-T TV, Car TFT LCD monitors , Car camera, Reversing system,
CCTV camera etc, a series of hi-tech technologyproducts’ research
and manufacture, marketing throughout all over the world

   廣州車嘉電子科技有限公司專業生產及銷售車載通用、專用DVD/GPS導航系統，汽車頭枕、臺式
后視鏡等液晶顯示器，車載全景系統、倒車攝像頭、倒車雷達、DVB-T\ISDB\ATSC-M\等一系列汽車
影音產品，產品遠銷歐美，日本，東南亞地區。
  Guangzhou CACAR Electronics Technology Co.,Ltd Specializing in car DVD，ISDB-T TV,
ATSC-M, DVB-T MPEG4, DVB-T TV, Car TFT LCD monitors , Car camera, Reversing system,
CCTV camera etc, a series of hi-tech technologyproducts’ research
and manufacture, marketing throughout all over the world

Image sensors:	CCD	CMOS
Image device:	MT9V136,PC1089K	PC1030
NSTC/TV System:	NTSC	NTSC
Minimum illumination.	< 0.5	< 0.5
AGC:	Auto	Auto
BLC:	Auto	Auto
White Balance:	Auto	Auto
Video Color:	Colorful	Colorful
Waterproof Class:	IP 68	IP 68
Effective Pixels:	728*512	580*495
Resolution:	480TV lines	420TV lines
Video Output:	1.0Vp-p, 75Ω	1.0Vp-p, 75Ω
Electronic Shutter:	1/60(NTSC)-1/10000S	1/60(NTSC)-1/10000S
S/N ratio:	Better Than 48db	Better Than 48db
Lens Angle:	170°	170°
Operation Temperature:	-20° C+80° C RH95%	-20° C+80° C RH95%
Storage Temperature:	-30° C+80° C	-30° C+80° C
Working Power (DCV):	12V	12V
Current consumption:	90mA Max	90mA Max
Warranty	12 months	12 months
